Keyestudio 8 Channel 5V Relay Module for Arduino PIC AVR MCU DSP ARM Electronic

KS0059
Price:
Quantity:
-
+
(876 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
Please select the information you wantX
  • Description
  • Features
  • Documents
  • Reviews

This module employs high quality relay with eight channels input and eight channels output. It can be connected to 250V/10A AC element or 24V/10A DC element to the maximum, therefore, it can be used to control lights, motors and etc.

The modularized design makes it easy to connect to Arduino expansion board. The output state of the relay is shown by a luminous diode for the convenience of actual application.


  • Control signal: TTL voltage

  • Rated load:
    10A 250VAC
    10A 125VAC
    10A 30DC
    10A 28VDC

  • Rated Through-current: 10A(NO) 5A(NC)

  • Max Switching Voltage: 250VAC 30VDC

  • Contact actuation time: <10ms

  • Definition of module pins:
    Pin 1 -Pin 8----Controlling end
    Power supply (VCC)
    Ground (GND)
